The A012 omnidirectional mobile robot platform has a wide range of applications, including manufacturing, logistics, healthcare, education, and research.
Its versatile design allows for customization to meet specific requirements, while its precise movement and high payload capacity enable efficient material handling and transportation.
Multi Moving Modes,All Terrain Robot Platform
Independent Suspension System
Modular Design
Robot Navigates 62cm Corridors and Turns in 72cm Spaces
Customizable
Size: 620*520*340mm
Weight: 50KG
Drive Form: 4WD-4WS（Four-Steering Four-Wheel Drive)
Motor: Wheel motor
Battery Capacity: 36V/30Ah
Charging Time: 3-4H
Charging Method: Manual & Automatic
Battery life: 6H
Power Output: 36V/30Ah
Braking: Motor Braking
Protocol: CAN2.0B
Payload: 50KG
Mileage: 30km
Speed: 0-7.92km/h
Climbing Capacity: 20°(full load 50kg)
Obstacle Clearance: 50mm (full load 50kg）
Protection Level: IP44
